Camera
Image Sensor 2 MP CMOS
Max. Resolution 1920 (H) × 1080 (V)
Min. Illumination 0.01 Lux @ (F2.0, AGC ON), 0 Lux with IR
Shutter Time PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s
Day & Night ICR
Angle Adjustment Pan: 0 to 360°, tilt: 0 to 180°, rotate: 0 to 360°
Signal System PAL/NTSC
Lens
Lens Type Fixed focal lens, 2.8 mm and 3.6 mm optional
Focal Length & FOV 2.8 mm, horizontal FOV: 100°, vertical FOV: 55°, diagonal FOV: 116°
3.6 mm, horizontal FOV: 80°, vertical FOV: 43°, diagonal FOV: 95°
Lens Mount M12
Illuminator
Supplement Light Type White Light, IR
Supplement Light Range IR : up to 20 m
White Light : up to 20 m
Image Settings Brightness, Sharpness, Smart IR
Frame Rate TVI: 1080P @30 fps, 1080P @25 fps
AHD: 1080P @30 fps, 1080P@25 fps
CVI: 1080P @30 fps, 1080P @25 fps
CVBS: PAL/NTSC
Day/Night Mode Auto/Color/BW (Black and White)
Wide Dynamic Range (WDR) Digital WDR
Image Enhancement DWDR/BLC/HLC/Global
White Balance Auto/Manual
AGC Yes
Interface
Video Output Switchable TVI/AHD/CVI/CVBS
Built-in Microphone Yes
General
Material Plastic
Dimension 161.22 mm × 57.97 mm × 61.96 mm (6.35 inch × 2.28 inch × 2.44 inch)
Weight Approx. 164 g (0.36 lb)
Operating Condition -40 °C to 60 °C (-40 °F to 140 °F). Humidity: 90% or less (non-condensation)
Language English
Power Supply 12 VDC ± 25%
*You are recommended to use one power adapter to supply the power for one camera.
Consumption Max. 3.2 W
Approval
Protection IP66
Available Model
PT-HTD11F0E-LPFS
